TP-Link 300Mbps Wireless N VDSL/ADSL Modem Router (TD-W9960)

Key Features

• HARDWARE
• Interface
• 3 10 / 100Mbps RJ45 LAN Ports
• 1 10 / 100Mbps RJ45 LAN / WAN Port
• 1 RJ11 Port
• Buttons
• WPS Button
• RESET Button
• Power ON / OFF Button
• External power supply
• 9VDC / 0.6A
• IEEE Standards
• IEEE 802.3, 802.3u
• VDSL2 Standards
• ITU-T G.993.2
• ITU-T G.993.5 (G.vector)
• ITU-T G.998.4 (G.INP)
• Dimensions (WxDxH)
• 181.6 * 129.7 * 36.2mm
• Antenna type
• Omni directional, Fixed
• Antenna gain
• 2 x 5dBi
• WIRELESS MODULE SETTINGS
• Wireless Networking Standards
• IEEE 802.11b, 802.11g, 802.11n
• Frequency range (reception and transmission)
• 2.400-2.4835GHz
• EIRP (Wireless signal power)
• <20dBm (EIRP)
• Wireless Security
• 64/128-bit WEP, WPA / WPA2, WPA-PSK / WPA-PSK2
• encryptions, Wireless MAC Filtering
• CHARACTERISTICS OF THE SOFTWARE
• QoS (data prioritization)
• WMM, Bandwidth Control (IP QoS)
• Security
• NAT Firewall, SPI Firewall, Denial of Service (DoS), SYN Flooding, Ping of Death, Access Control, Service Filtering, IP and MAC Address Binding
• Operating modes
• VDSL / ADSL Modem Router, Wireless Router,
• Control
• Web Based Configuration (HTTP), Remote Management, CWMP (TR-069), Web Based Firmware Upgrade, Diagnostic Tools
• Port Forwarding
• Virtual Server, Port Triggering, DMZ, ALG, UPnP
• VPN traffic skip
• IPSec VPN
• Protocols
• Supports IPv4 and IPv6
• ATM / PPP protocols
• PPPoE (RFC2516)
• PPPoA (RFC 2364)
• MER \ IPoE (RFC 1483 Routed)
• IPoA (RFC1577 / 2225)
• Bridge (RFC1483 Bridge)
• Additional Features
• Parental Controls, Network Address Translation (NAT), Port Mapping (Grouping), Static Routing, RIP v1 / v2 (optional), DNS Relay, DDNS, IGMP V1 / V2 / V3
• APP
• Tether App
• OTHER
• Certification
• CE, RoHS
• System requirements
• Microsoft Windows 98SE, NT, 2000, XP, Vista ™ or Windows 7, 8, 8.1, 10,
• the Mac OS, the NetWare, the UNIX or the Linux
• of Internet Explorer 11, of Firefox 12.0, the Chrome 20.0, the Safari 4.0, or OTHER
• the Java-the enabled browser
• the Subscription With an internet service provider (for internet access)
• Environmental parameters
• Operating Temperature: 0 ℃ ~ 40 ℃ (32℉ ~ 104℉
• Storage ) Storage Temperature: -40 ℃ ~ 70 ℃ (-40℉ ~ 158℉)
• Operating Humidity: 10% ~ 90% non-condensing
• Storage Humidity: 5% ~ 90 % Non-condensing

Product Detail

What Is In The Box

1 X TP-Link 300Mbps Wireless N VDSL/ADSL Modem Router (TD-W9960)
